Wireless monitoring systems let directors, DOPs, script supervisors, and other crew members view a live camera feed on their monitor without any cable connecting them to the camera. The VITA series offers two monitoring systems — VITA PRO and Vita Lite — with different range, form factor, and feature sets. This guide compares them to help you choose the right system for your production across the UK.
What Do Wireless Monitoring Systems Do?
A wireless monitoring system transmits the camera's video output (HD-SDI or HDMI) to one or more receivers placed wherever crew members need to see the picture. Unlike camera control or video transmission systems, monitoring systems carry video only — no camera control data and no IP data. Both VITA PRO and Vita Lite deliver sub-1 ms system latency, support metadata and record trigger, and operate on 5.1–5.9 GHz OFDM frequencies.
What Are the Key Differences Between VITA PRO and Vita Lite?
The two systems share the same core technology but are built for different production scenarios.
VITA PRO System
- Range: Up to 600 m line-of-sight
- Antennas: Enhanced multi-antenna diversity with external RP-SMA antennas
- Outputs: 2x HD-SDI + HDMI
- Form factor: Larger housing with robust antenna connectors for demanding environments
- Best for: Outside broadcast, live events, stadium productions, and any scenario where camera-to-monitor distances are substantial or the RF environment is challenging
Vita Lite System
- Range: Up to 300 m line-of-sight
- Antennas: Internal antennas for a clean, snag-free form factor
- Outputs: 1x HD-SDI + HDMI
- Weight: 260g (TX) / 240g (RX) — among the lightest in the category
- Best for: Studio, controlled indoor environments, handheld rigs, gimbal setups, and compact productions where weight and size matter more than extended range
When Should You Choose VITA PRO?
Choose VITA PRO when your production involves longer distances between camera and monitoring positions, outdoor environments where line-of-sight may be variable, or venues with heavy RF congestion. The enhanced multi-antenna diversity gives the receiver more signal paths to work with, improving reliability in challenging conditions. The dual HD-SDI outputs also allow daisy-chaining to additional monitors or feeding directly into production infrastructure.
When Should You Choose Vita Lite?
Choose Vita Lite when weight and size are priorities. At 260g for the transmitter and 240g for the receiver, it adds minimal bulk to a handheld rig, Steadicam, or gimbal. The internal antennas eliminate snag points in tight spaces. The 300 m line-of-sight range is sufficient for most studio and controlled indoor environments where camera-to-monitor distances are shorter.
Can You Expand a VITA Monitoring Setup?
Yes. The VITA series is modular — you can add individual transmitters and receivers to expand coverage.
- Vita Transmitter (TX only): Add to put another camera's feed on the wireless monitoring system. HD-SDI loop output, 2x RP-SMA antennas, 260g. From £50/day. View product page
- Vita Lite Receiver (RX only): Add to create another monitoring point. Internal antennas, 240g, HD-SDI + HDMI output. From £80/day. View product page
When used as part of a compatible VITA wireless link, additional transmitters and receivers deliver sub-1 ms system latency matching the main system.
How Do You Hire VITA Monitoring Equipment?
WaveHire offers VITA monitoring systems for hire across the UK. Every system is fully tested and paired before dispatch. Equipment can be shipped 1–2 days before your production anywhere in the UK, or collected same-day from our London facility. Contact the team to confirm exactly what is included with your hire and discuss any accessories you need.
